Frame Size

104mm

Shaft/Gear Type

Combination Type – Parallel Shaft Gearhead

Gear Ratio

100

Electromagnetic Brake

With

Included Cable

3m

Rated Output Power (Continuous)

200W

Power Supply Input Rated Voltage

DC24V

Power Supply Input Permissible Voltage Range

±10%

Power Supply Input Rated Input Current

13A

Power Supply Input Maximum Input Current

25A

Rated Torque (Motor Shaft)

0.65N・m

Starting Torque (Motor Shaft)

1.15N・m *1

Rated Speed (Motor Shaft)

3000r/min

Speed Control Range

1-40r/min

Permissible Torque

52.7N･m（1-30r/min）
36.5N･m（40r/min）

Permissible Load Inertia J

18000×10^-4kg・m^2

Permissible Load Inertia J (When instantaneous stop or instantaneous bi-directional operation is performed)

5000×10^-4kg・m^2

Rotor Inertia J

0.61×10^-4kg・m^2

Speed Regulation (Load)

±0.5% (±0.2%) max. *2
[0∼Rated torque, at rated speed, at rated voltage, at normal ambient temperature]

Speed Regulation (Voltage)

±0.5% (±0.2%) max. *2
[Rated voltage ±10%, at rated speed, with no load, at normal ambient temperature]

Speed Regulation (Temperature)

±0.5% (±0.2%) max. *2
[0～+40˚C (+32～+104˚F), at rated speed, with no load, at rated voltage]

Electromagnetic Brake Type

Power off activated type, automatically controlled by the driver *3

Electromagnetic Brake Static Friction Brake

0.65N・m

CE Marking

affixed

Speed Setting Method

Select one of the following methods:
・Internal speed potentiometer (VR1)
・External analog setting (External speed potentiometer or external DC voltage)

Acceleration Time / Deceleration Time

Acceleration and Deceleration time potentiometer (VR2):
0.2～15 seconds (3000 r/min with no load)

Multi-Speed Setting Method

2 Speeds: 1 speed set by the internal speed potentiometer and 1 speed set by the external analog setting.

Protective Function

Overload, sensor abnormality, initial sensor abnormality, overvoltage, undervoltage, overspeed, overcurrent, EEPROM error, main circuit overheat, external stop, initial operation stop, communication switch setting error, main circuit output abnormality

Max. Extension Distance

Motor/Driver Distance: 3.5 m (11.5 ft.)

Time Rating

Continuous

Mass: Motor

6.4kg(Including gearhead)

Mass: Control Circuit

0.6kg
